• 2 megapixel progressive CMOS sensor
• Up to 1080p resolution
• OSD menu, DNR, Smart IR, AGC
• IR cut filter
• True WDR
• Internal 3-axis adjustment
• Built-in microphone
• Up the Coax (HIKVISION-C)
Call for Price
SKU: AE-VC211T-IRS(2.8mm)
Categories: All Products, Mobile Camera, Mobile HD-TVI Camera
Tags: 120db WDR, Automatic White Balance, Built-in Microphone, CCTV, HD, Hikvision, Hikvision Mauritius, InfraRed, Mobile HD-TVI Camera, True WDR
Specification
Description
| Camera | ||
|---|---|---|
| Image Sensor: | 2MP CMOS Image Sensor | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1964 (H) × 1116 (V) | |
| Min. Illumination: | 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens: | 3.6 mm (2.8 mm, and 6 mm are selectable) | |
| Lens Mount: | M12 | |
| Adjustment Range: | Pan: -30°to 30°, Tilt:0°to 75°, Rotate: -180°to 180° | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | 120dB | |
| Video Frame Rate: | 1080p@25fps/1080p@30fps | |
| Synchronization: | Internal Synchronization | |
| Video Output: | 1Vp-p Composite Output (75Ω/BNC) | |
| S/N Ratio: | More than 62 dB | |
| BLC: | Support | |
| Up the Coax: | Support | |
|
Menu |
||
|---|---|---|
| D/N Mode: | Color/BW/SMART | |
| Auto White Balance: | Auto / Manual | |
| BLC: | Support | |
| AGC: | Support | |
| Language: | English/Chinese | |
| Function: | Brightness, Contrast, Saturation, Sharpness, Digital noise reduction, Mirror | |
|
Interface |
||
|---|---|---|
| Audio In: | Built-in Microphone | |
| Audio Out: | 1-ch, Aviation Port (Linear Level, 1KΩ) | |
| Video Out: | 1-ch, Aviation Port | |
|
General |
||
|---|---|---|
| Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: | 12 VDC±15% | |
| Power Consumption: | Max. 4 W | |
| Impact Protection: | IK7 | |
| IR Range: | Approx 10 to 20 meters | |
| Dimension: | 97 mm × 99.5 mm × 46.6 mm (3.82″ × 3.92″ × 1.83″) | |
| Weight: | Approx. 300 g (0.66 lb.) | |
Datasheet of AE-VC211T-IRS series
| Category | Line | Default Warranty Period(Month) |
|---|---|---|
| Analog cameras | Analog cameras | 24 |
| DVR | 7 Series DVR | 24 |
| 89 Series DVR | 36 | |
| Board | 24 | |
| DVS | DVS | 24 |
| Hilook | Hilook | 12 |
| IP cameras (IPC) | 1 Series IPC | 12 |
| 2 Series IPC | 24 | |
| 4/5/7/8 Series IPC | 36 | |
| 6 series IPC | 36 | |
| Zoom camera/zoom camera module | 36 | |
| Speed dome | AE/DE Series speed dome | 24 |
| AF/DF Series speed dome | 36 | |
| PTZ | 36 | |
| Anti-corrosion/anti-explosion | 36 | |
| Thermal imaging | Thermal imaging | 36 |
| NVR | 7 Series NVR | 24 |
| 89 Series NVR | 36 | |
| Hilook | Hilook | 12 |
| Large screen | LCD | 12 |
| LED | 12 | |
| DLP | 12 | |
| Displayer (≤24 inches) | 12 | |
| Displayer (>24 inches) | 12 | |
| Interactive display | 12 | |
| Information release screen | 12 | |
| Control | Integrated platform | 24 |
| Decoder | 36 | |
| Video wall controller | 36 | |
| Transmission | Optical transceiver/switch | 24 |
| Transmission cable | 60 | |
| All-in-one server | Blazer | 36 |
| Storage | SAN | 36 |
| Data center | Data center | 24 |
| Universal server | 36 | |
| Intelligent transportation system | Traffic cameras | 24 |
| Supplement light and auxiliary | 24 | |
| Traffic server | 24 | |
| Signal control | 24 | |
| RFID | 24 | |
| Mobile | Mobile | 24 |
| Portable terminal | PVR system | 24 |
| Portable speed dome | 24 | |
| Body camera | 24 | |
| Others | 24 | |
| Entrance & exit | Entrance & exit | 24 |
| Parking lot | 24 | |
| Access control | Access controller | 24 |
| Access control terminal | 24 | |
| Card reader | 24 | |
| Card issuer /card enrollment station | 24 | |
| Access Portal | 12 | |
| Lock | Smart lock | 12 |
| Intercom | Video intercom | 24 |
| Alarm | Emergency alarm | 24 |
| Auto-alarm（excluding Pyronix） | 36 | |
| Consumer storage device – portable storage | M100 Series | 12 |
| Portable T100 Series | 36 | |
| Consumer storage device – NAS | W100 Series | 12 |
| H100 Series | Device: 24
HDD/SSD: 36 |
|
| Consumer SSD | E100, E100N/E1000N Series | 36 or SSD lifespan, whichever occurs first. |
| Enterprise SSD | S100, S200 Series | 36 or SSD lifespan, whichever occurs first. |
| Surveillance SSD | V100/V200 Series | 36 or SSD lifespan, whichever occurs first. |
| Consumer memory card | E1/E10 Series | 84 or memory card lifespan, whichever occurs first. |
| Surveillance memory card | H1, L1/L2, H10 Series | 24 or memory card lifespan, whichever occurs first. |
| EZVIZ | All Series | 12 Months |
