- High quality imaging with 2 MP resolution
- Excellent low-light performance via powered-by-DarkFighter technology
- Clear imaging against strong back lighting due to 120 dB WDR technology
- Pan and tilt ability enables camera to monitor zones of interest
- 25x optical zoom allows for closer viewing of subjects in expansive areas
- Up to 150m IR range ensures safety at night
- Water and dust resistant (IP66);
Call for Price
Specification
Description
Lens
| FOV |
Horizontal field of view: 57.6° to 2.5° (wide to tele) Vertical field of view: 34.4° to 1.4° (wide to tele) Diagonal field of view: 64.5° to 2.9° (wide to tele) |
| Zoom Speed | Approx. 3.6 s (optical, wide to tele) |
| Working Distance | 10 mm to 1500 mm (wide to tele) |
| Aperture Range | F 1.6 to F 3.5 |
| Focal Length | 4.8 mm to 120 mm, 25× Optical |
| Max. Resolution | 1920 × 1080 |
Camera Module
| Frame Rate |
50Hz: 25fps @(1920 × 1080) 60Hz: 30fps @(1920 × 1080) |
| AGC | AUTO/MANUAL |
| DNR | 3D DNR |
| Regional Focus | Yes |
| Image Sensor | 1/2.8″ progressive scan CMOS |
| Model | DS-2AE5225TI-A(C) |
| Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON) 0 lux with IR |
| White Balance | AUTO/MANUAL/HAUTO/ATW/INDOOR/OUTDOOR |
| Shutter Time |
PAL: 1/1 s to 1/10,000 s NTSC: 1/1 s to 1/10,000 s |
| Day & Night | IR cut filter |
| Digital Zoom | 16× |
| Privacy Mask | 8 programmable privacy masks |
| Focus Mode | Auto/Semiauto/Manual |
| WDR | ≥ 120 dB |
| BLC | Yes |
| HLC | Yes |
| EIS | Yes |
PTZ
| Movement Range (Pan) | 360° endless |
| Pan Speed |
Pan manual speed: 0.1° to 120°/s Pan preset speed: 120°/s |
| Movement Range (Tilt) | -15° to 90° (auto flip) |
| Tilt Speed |
Tilt manual speed: 0.1° to 80°/s Tilt preset speed: 80°/s |
| Proportional Zoom | Rotation speed can be adjusted automatically according to zoom multiples |
| Presets | 256 |
| Patrol Scan | 10 patrols, up to 32 presets per patrol |
| Pattern Scan | 5 patterns, with the total recording time no less than 10 minutes |
| Power-Off Memory | Yes |
