- High quality Omni-directional microphone sensor
- Fully remote configurable through App
- Multiple enrollment method and easy installation design
- Easy replaceable battery with PCB protected
- Frequency hopping against jamming for reliable transmission
Call for Price
SKU: DS-PDBG8-EG2-WE
Categories: Alarm System, All Products, Hikvision AX PRO
Tag: Hikvision AX Pro Alarm System
Specification
Description
|
Detection Performance
|
|
|
Detection Method
|
Acoustic Sensor
|
|
Detection Range
|
8m
|
|
Detection Angle
|
120°
|
|
Sensitivity
|
2m;4m;6m;8m
|
|
Glass Type
|
Float;Plate;Tampered;Wired;Laminated Leaded;Double Glazing
|
|
Glass Thickness
|
2.4mm to 6.4mm
|
|
Glass Size
|
0.3m x 0.3m to 3m x 3m
|
|
Feature
|
|
|
Digital Processing
|
Support
|
|
Tamper Protection
|
Front;Rear
|
|
Environment Temperature Indicator
|
Support
|
|
Signal Strength Indicator
|
Support
|
|
Interface
|
|
|
Alarm Input
|
Normally Closed;Normally Open;Impulse Count
|
|
Power Switch
|
Power Up Enrolling
|
|
LED Indicator
|
Blue(Alarm)
|
|
Transmission
|
|
|
Transmission Technology
|
Tri-X Wireless
|
|
Transmission Method
|
Two-Way RF Wireless
|
|
Transmission Frequency
|
868MHz
|
|
Transmission Security
|
AES-128 Encryption
|
|
Transmission Range(Free Space)
|
1.6Km
|
|
Frequency Hopping
|
Support
|
|
Enrolling Method
|
Power up;Remote ID;QR Code
|
|
Electrical Characteristics
|
|
|
Power Supply
|
Battery Powered
|
|
Battery Type
|
CR123A × 2
|
|
Typical Voltage
|
3V
|
|
Standard Battery Life
|
5 years in work status (being triggered 20 times per day)
|
|
General
|
|
|
Operation Temperature
|
-10 °C to 55 °C (14 °F to 131 °F)
|
|
Storage Temperature
|
-20 °C to 60 °C (-4 °F to 140 °F)
|
|
Operation Humidity
|
10% to 90%
|
|
Dimension(WxHxD)
|
38.8mm × 107.0mm × 24.5mm
|
|
83g
|
|
|
Mounting Method
|
Wall;Ceiling
|
|
Application Scenario
|
Indoor
|
Data Sheet
User Manual
Qucik Start Guide
