• 3 Megapixel high-performance CMOS
• Analog HD output, up to 3MP resolution
• 2.8-12mm motorized vari-focal lens
• True Day/Night
• OSD menu, DNR, Smart IR
• True WDR, up to 120dB
• EXIR technology, up to 40m IR distance
• IP66 weatherproof
• Up the Coax(HIKVISION-C)
Call for Price
SKU: DS-2CE56F7T-IT3Z
Categories: 3 Megapixel Camera, All Products, Analog Cameras, Dome Camera, EXIR Technology, Motorized VF, Turbo HD, Turret Camera, Vari-focal
Tags: 3 Megapixel Camera, 5 Megapixels, Analog Camera, Automatic White Balance, Bullet Camera, CCTV, Digital WDR, EXIR Technology, HD, Hikvision, Hikvision Mauritius, InfraRed, IP67, Mobile Remote Surveillance, Turbo HD, Turbo HDMotorized VF, Turret Camera, Vari-focal
Specification
Description
| Camera | ||
|---|---|---|
| Image Sensor: | 3MP CMOS Image Sensor | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 2052(H)*1536(V) | |
| Min. Illumination: | 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens: | Motorized VF lens; 2.8 – 12 mm angel of view: 26.8°-83° |
|
| Lens Mount: | φ14 | |
| Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 75°, Rotation: 0 – 360° | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | 120dB | |
| Video Frame Rate: | 1920 ×1536@18fps | |
| HD Video Output: | 1 Analog HD output | |
| Synchronization: | Internal Synchronization | |
| S/N Ratio: | More than 62 dB | |
| Up the Coax: | Support | |
|
Menu |
||
|---|---|---|
| Auto White Balance: | Auto/MWB | |
| BLC: | Support | |
| AGC: | Support | |
| Language: | English/Chinese | |
| Function: | Wide Dynamic Range; Digital Noise reduction; Mirror; SMART IR | |
|
General |
||
|---|---|---|
| Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: | 12 VDC±15% | |
| Power Consumption: | Max. 6W | |
| Weather Proof: | IP66 | |
| IR Range: | Up to 40m | |
| Communication : | Up the coax Protocol: HIKVISION-C(Coaxitron) |
|
| Dimension: | 134.3mm×123.9mm×111.4mm (5.29”×4.88”×4.39”) | |
| Weight: | Approx. 750g (1.57lb) | |
Datasheet of DS-2CE56F7T-IT3Z
User Manual of DS-2CE56F7T-IT3Z
